ALI # 106335



Here is another great offering from Asset Liquidity's offset and bindery equipment. The Heidelberg Speedmaster SM 52-5 P3H is a high-end 5‑color offset press in the 37×52 cm format class, designed for commercial printing with high quality and automation.

  • Format: 370 mm × 520 mm (14.57″ × 20.47″)

  • Max. print format: 360 mm × 520 mm (14.17″ × 20.47″)

  • Min. sheet size: 105 mm × 145 mm (4.13″ × 5.71″)

  • Blanket cylinder: 459 mm × 525 mm (metal-backed), 0.10–0.15 mm thick

  • Packing sheet: 377 mm × 532 mm

  • Cylinder undercut: 0.03 mm

  • Gripper margin: 8–10 mm

  • Feeder: Standard 915 mm (36.02″)

  • Max. plate cylinder speed: 15,000 sheets/hour (basis SM 52‑4)

  • Number of printing units: 4 (5‑color)

  • Weight: ~11,100 kg (varies by configuration)

  • Dimensions: ~7025 mm × 1850 mm × 1620 mm (L×W×H)
