Horizon makes a machine that is ready to for any project. This is a great offering from Asset Liquidity's offset and bindery printing equipment.
Details

1. Manufacturer: Horizon

2. Model: RD-4055DM

3. Year: 2019

4. Max. Sheet Size: 15.74" x 21.65"

5. Min. Sheet Size: 7.875" x 10.83"

6. Feeder Stacker Height: 19.68"

7. Material Thickness: 127.9 to 400gsm Die Cutting: Max. 0.5 mm or 0.019" Creasing: Max. 0.3 mm or 0.011"

8. Production Speed: 6,000 cycles per hour

9. Double sheet detection: Ultrasonic and mechanical

10. Processed Material: Normal paper, Coated paper, Cardboard The sheets below cannot be processed: Sheet whose back side is laminated (cover with polypropylene) Plastic film

11. Available Cutting Area: 14.8" W x 20.8" L

12. Die Size - Upper Die: Max. 15.74" W x 22.04" L Min. 6.30" W x 3.94" L

13. Upper Cutting Blade Height: 0.0315"

14. Gripping width for Repeat Die Cutting: 6.69"(includes the cut product at least)

15. Dimensions: With separator: 141.2" W x 32.3" D x 47.1" H Weight: 1,962.45 lb

16. Air Requirements: Rated Output of Prime Mover(Reference): 0.75 kW Maximum Operating Pressure: 0.8 MPa Minimum Required Pressure: 0.6 MPa or more Minimum Discharge: 85 Liters per minute Type: Oil-free Type

17. Electrical: Single Phase 200 to 240 V, 50 or 60 Hz
